Percipitation

  • Small timespan: Hourly cummulative
  • Larger timespan: Daily cummulative
  • Individual value range: 0 – 50mm

Relative Humidity

This variable is retrieved from the API as a fraction, please multiply by 100 to get percentages.

  • Small timespan: Hourly averages
  • Larger timespan: Daily averages
  • Individual value range: 0 – 150%

Pressure

  • Small timespan: Hourly Averages
  • Larger timespan: Daily Averages
  • Individual value range: 50 – 150kPa

Radiation

  • Small timespan: Hourly averages
  • Larger timespan: Averages per 3hours
  • Individual value range: 0 – 1500W/m2

Temperature

  • Small timespan: Hourly averages
  • Larger timespan: Averages per 3hours
  • Individual value range: (-50) – (+100) C%

Wind Speed

The TAHMO_VAR009 is the measurement data, please use this one.

  • Small timespan: Hourly averages
  • Larger timespan: Averages per 3hours
  • Individual value range: 0 – 100ms

Wind Direction

Classify each measurement into a direction (N, NE, E, SE, S, SW, W, NW),
Direction North are values above 337.5 and below 22.5, North-east values between 22.5 and 67.5 etc….
The direction with most occurrences within the specified timeframe will be the representing value.

  • Small timespan: Hourly dominant direction
  • Larger timespan: Daily Dominant Direction
  • Individual value range:0 – 360 degrees
